ION Harness how to guide.

Everything you need to know.

The kind dudes at ION have put together 'how to' guides and videos to help with every task and change you will ever need to do on your awesome ION Harness.

Spectre Bar 2

Installing the minirope - Spectre Bar 2

Step 1: Remove all five screws from the inside of your Spectre Bar 2 using a TX20 Torx driver.

Step 2: Carefully remove the pad, flaps, and hook.

Step 3: Remove the front cover by pushing the two small plastic tabs on each side of the bar.

Step 4: Replace the original cover with the enclosed replacement part.

Step 5: Make a figure-eight knot on one side oft he mini rope.

Step 6: Run the mini rope through one of the holes on the Spectre Bar 2.

Step 7: Run the mini rope back through the other hole.

Step 8: Secure it with another figure-eight knot on the inside.

Step 9: Thread the webbing slider through the Spectre Bar 2.

Step 10: If using a stanndard chicken loop, add the stainless steel ring. If using the Duotone Rope Kit, the ring is not needed.

Step 11: Place the rope cover over the webbing slider.

Step 12: Insert the two screws next to the center through the rope cover and rope.

Step 13: Tighten the screws holding the hook to 2.5Nm. Tip: you can adjust the rope length.

Step 14: Long rope: Use both inner holes. Medium rope: Use one inner and one outer hole. Short rope: Use both outer holes.

Step 15: Secure everything tightly.

Step 16: Reassemble the flaps and pad, including the washers. Fasten with the remaining three screws.

Installing the Slider - Spectre Bar 2

Step 1: Remove all five screws from the inside of your Spectre Bar 2 using a TX20 Torx driver.

Step 2: Carefully remove the pad, flaps, and hook.

Step 3: Thread the webbing slider through the Spectre Bar 2.

Step 4: If using a standard chicken loop, add the stainless steel ring. If using the Duotone Rope Kit, the ring is not needed.

Step 5: Place the rope cover over the webbing slider.

Step 6: Insert the two screws next to the center through the rope cover and rope.

Step 7: Tighten the screws holding the hook to 2.5Nm.

Step 8: Tip: You can adjust the rope length. Long rope: Use both inner holes. Medium rope: Use one inner and one outer hole. Short rope: Use both outer holes.

Step 9: Secure everything tightly.

Step 10: Reassemble the flaps and pad, including the washers. Fasten with the remaining three screws.



Spectre Bar

How to change the hook on the Spectre Bar

Step 1: Remove the three middle screws that secure the hook of the Spectre bar using a TX20 Torx

Step2: Remove the hook from the Spectre bar

Step 3: Put the place holder back into it's original position

Step 4: Add new hook to the Spectre barS

Step 5: Put the three screws back into their original position. Make sure the longest 20mm screw is in the center



How to install the webbing slider on the Spectre Bar

Step 1: Remove all five screws from the inside of your Spectre Bar using a TX20 Torx

Step 2: Carefully, remove the pad, flaps & hook

Step 3: Assemble the hook place holder

Step 4: Run the webbing slider through the Spectre Bar

Step 5: Cut the webbing slider to your preferred length

Step 6: If you are using a standard chicken loop, add the stainless steel ring. If you are using the Duotone Rope Kit you don't need the ring

Step 7: Place the aluminium bar on top of the webbing slider

Step 8: Put the screws through the aluminium bar & through the webbing slider. Secure tightly.

Step 9: Add the hook place holder, reassemble the flaps & secure everything with the screws. Make sure to put the longest screw in the center.



How to install the webbing slider + mini rope on the spectre bar

Step 1: Remove all five screws from the inside of your Spectre Bar using a TX20 Torx

Step 2: Carefully, remove the pad, flaps & hook

Step 3: Remove the front cover by pushing the two small plastic tabs on each side of the bar

Step 4: Replace the original cover the the enclosed replacement part

Step 5: Make a figure-eight knot on one side of the mini rope

Step 6: Run the mini rope through one side of the aluminium bar

Step 7: Now run it through one of the holes of the Spectre Bar

Step 8: Run the mini rope back through the other hole in the Spectre Bar. Secure it with another figure-eight knot on the inside

Step 9: Install the webbing slider according the instruction (see above)



How to remove the flaps on the spectre bar

Step 1: Using a Torx TX20 remove the two outer screws on the inside of your Spectre Bar

Step 2: Remove the flaps by pulling them downwards

Step 3: Put both screws back in and secure them tightly



C-Bar 3

How to change the hooks

The C-Bar 3.0 is delivered with Webbing Slider, but without hook

Step 1: Remove the three screws on the EVA pad

Step 2: Remove the placeholder

Step 3: Insert the hook of your choice from above between bar and pad.

Step 4: Tighten the hook with three screws

Step 5: Ready to shred!

Note: The placeholder removed in step 2 may be locked away.

How to adjust the webbing slider

Step 1: Pull the clamp out of the slot inside of the EVA pad

Step 2: Remove the screws of the clamp

Step 3: Move clamp position to your desired webbing length

Step 4: Attach clamp and tighten screws. Important: Do not turn the screw through the webbing, just pass it at the side.

Step 5: Stow the clamp and end of the slider back inside the pad

Step 6: Ready to shred!





How to replace the Releasebuckle VI_C30 Buckles



How to remove the handle?



Still having trouble with your harness? Then why not contact the shop on 01202 733744 and get one of our H2O Sports experts to help!
